FN110 Field Wireless Communication Module
Brand: Yokogawa Electric Corporation
The FN110 Field Wireless Communication Module is a core device in the field wireless network used for configuration and management of a field wireless network and for data transfer to the host system.
When utilized with the Field Wireless Multi-Protocol Module FN310 or Field Wireless Multi-Function Module FN510, this product is connectable with a field wireless network as a field wireless device.
FeaturesBuilt-in high-performance wireless communication function
- This module has excellent radio sensitivity and low power consumption, providing a stable wireless communication platform with excellent power saving capabilities.
Compact and lightweight
- The FN110 has been made compact and extremely lightweight as an explosion proof antenna with a built-in wireless communication module. As a result, flexible installation in the industrial environment is possible.
ISA100 Wireless protocol stack
- Digital communication for FN series is specified, this product is supplied with an ISA100 Wireless certified protocol stack with excellent reliability and scalability. ISA100 Wireless is an international, industrial wireless networking standard engineered to serve the needs of process industries.
Built-in wireless gateway
- Modbus communication for PLC/RTU is specified, this product acts as system manager, security manager, gateway, and backbone router based on ISA100.11a. Easy to construct small scale field wireless network by combining it with the Remote Terminal Unit (RTU) or another controller.
Specifications
Ambient Temperature Range
- -40° to 70° C (-40° to 158° F)
Approvals & Certifications
- R & TTE Directive
Approvals & Certifications
- ATEX Intrinsically Safe
- CE EN 61010-1, EN 62479
- CSA IEC 60529
- EMC EN 301 489-1, EN 301 489-17, EN 61326-1 Class A, EN 55011 Class A
- FCC
- FM Intrinsically Safe
- IC
- IEC Ex Intrinsically Safe
Cable Length
- 9.84 to 65.61 ft (3 to 20 metres)
Communication
- Baud Rate: 250 Kbps
- Baud Rate: 9600 bit/sec
- Half-Duplex
- ISA100-Wireless (IEEE 802.15.4)
- RS-485 Compliant
Consumption
- 60 mA - Consumption Current
Diagnostics
- Firmware Internal Error
- Memory Error
- Power Failure
- Wired Communication Failure
Distance
- Maximum
Electrical Connectors
- 5-Pin Round Connector Dedicated
Enclosure, Body Material
- Brass
Environmental Protection
- IP66
- IP67
- NEMA 4X
- Water-Proof
Frequency
- 2,400 to 2,483.5 MHz - License Free ISM Band
Humidity
- 0 to 100 % RH, Non-Condensing - Ambient Humidity (Operating, Storage)
Mounting
- 2" Pipe Mounting Bracket
Mounting Position
- Horizontal
- Vertical
Operating Temperature
- -40° to 85° C (-40° to 185° F) - Attitude up to 3,000 metres
Power
- 12 dBm (eirp) - RF Transmitter Power
Shock
- 50 G, 11 ms - Shock Resistance
Storage Temperature
- -40° to 85° C (-40° to 185° F)
Supply Voltage
- 2.9-4.8 V - Power Supply Voltage
Temperature Effect
- ± 10° C/hour (± 18° F/hour) or Less - Ambient Temperature Gradient (Operating)
- ± 20° C/hour (± 36° F/hour) or Less - Ambient Temperature Gradient (Storage)
Update Time
- 1 to 3,600 seconds
Vibration
- 0.21 mm Peak-to-Peak (10-60 Hz), 3 G (60-2 kHz) - Vibration Resistance
